Butterfly Valves
·Design as per API 609, MSS SP-67, AWWA C504, BS 5155 etc.
·Centric, Double Offset or Triple Offset
·Bi-Directional Seal
·Blow-out Proof Shaft
·Multi-layer Seat, Metal or Soft Seat
·ISO 5211 Top Flange
·NACE MR 0175/NACE MR 0103, HIC/SSCC
·Extend Shaft
·Pup Piece(With Nipple)
·Fugitive Emission, Vacuum Isolation
·With Locking Device
·With Counter Flange, Gasket, Fastener
| Type : | Butterfly Valve |
| Size : | 2”-100” (DN15-DN2500) |
| Pressure Rating : | Class 150-600 (PN16-PN100) |
| Body Material : | Gray Cast Iron, Ductile Cast Iron, Carbon Steel, Stainless Steel, Alloy Steel |
| Trim Material : | Carbon Steel, Stainless Steel, Alloy Steel, Duplex Steel etc. |
| Sealing Material: | DPDM, NBR, PTFE, VITON |
| Operation : | Wrench, Gear Box, Electric, Pneumatic etc. |
| End Connection : | Wafer, Lug, Double Flange |
